OEM Types Of Film Capacitors Manufacturers - Metallized Polypropylene Film Capacitor CBB21 – JEC
OEM Types Of Film Capacitors Manufacturers - Metallized Polypropylene Film Capacitor CBB21 – JEC Detail:
CBB21 250V
CBB21 400V
CBB21 450V
CBB21 630V
CBB23 1000V
CBB23 1200V
CBB23 1600V
CBB81 1000V
CBB81 1250V
|
Technical requirements reference Standard |
GB/T 14579 (IEC 60384-17) |
|
Climatic Category |
40/105/21 |
|
Operating Temperature |
-40℃~105℃（+85℃~+105℃：decreasing factor1.25% per℃ for UR） |
|
Rated Voltage |
100V, 250V, 400V, 630V, 1000V |
|
Capacitance Range |
0.001μF~3.3μF |
|
Capacitance Tolerance |
±5%(J),±10%(K) |
|
Withstand Voltage |
1.5UR,5sec |
|
Insulation Resistance(IR) |
Cn≤0.33μF,IR≥15000MΩ ;Cn>0.33μF,RCn≥5000s at 100V,20℃,1min For 60sec / 25℃ For 60sec / 25℃ |
|
Dissipation Factor (tgδ) |
0.1% Max, at 1KHz and 20℃ |
Application Scenario
Charger
LED lights
Kettle
Rice cooker
Induction cooker
Power supply
Sweeper
Washing machine
CBB21 is suitable for DC blocking, bypassing and coupling of DC and VHF level signals.
Mainly used in televisions, computer monitors, energy-saving lamps, ballasts, communication equipment, computer network equipment, electronic toys, etc.
Our company adopts advanced production equipment and instruments, and organizes production in strict accordance with the requirements of ISO9001 and TS16949 systems. Our production site adopts “6S” management, ensuring the stability and reliability of products. We produce products of various specifications in accordance with International Electrotechnical Standards (IEC) and Chinese National Standards (GB).
Certifications
Certification
JEC factories are ISO-9000 and ISO-14000 certified. Our X2, Y1, Y2 capacitors and varistors are CQC (China), VDE (Germany), CUL (America/Canada), KC (South Korea), ENEC (EU) and CB (International Electrotechnical Commission) certified. All of our capacitors are in line with the EU ROHS directives and REACH regulations.
About Us
Plastic bag is the minimum packing. The quantity can be 100, 200, 300, 500 or 1000PCS.
The label of the RoHS includes the product name, specification, quantity, lot No, manufacture date etc.
One inner box has N PCS bags
Inner box size (L*W*H)=23*30*30cm
Marking for RoHS AND SVHC
Product detail pictures:
Related Product Guide:
Our personnel are always inside the spirit of "continuous improvement and excellence", and together with the outstanding excellent goods, favorable price and good after-sales services, we try to gain every customer's trust for OEM Types Of Film Capacitors Manufacturers - Metallized Polypropylene Film Capacitor CBB21 – JEC , The product will supply to all over the world, such as: Turin, Chile, Sevilla, "Good quality and reasonable price" are our business principles. If you are interested in our products or have any questions, make sure you feel free to contact us. We hope to establish cooperative relationships with you in the near future.
By Bess from Australia - 2017.06.16 18:23
The product classification is very detailed that can be very accurate to meet our demand, a professional wholesaler.
By Eleanore from Belarus - 2018.11.02 11:11
