Zinc Oxide Varistor
05D
07D
10D
14D
20D
25D
| Technical Data | |
|
Model Size |
Ф5mm ~ Ф20mm |
|
Operating/Storage Temperature |
-40℃ ~ +85℃(+125℃ VDE)/-40℃ ~ +125℃ |
|
Withstanding Surge Current |
100~6500A |
|
Approved Monogram |
UL, VDE, CSA, CQC |
|
Series |
Maximun Allowable Voltage |
Varistor Voltage |
Maximun Clamping Voltage |
||||
|
|
AC rms(V) |
DC(V) |
Min. |
Vb(Vdc) |
Max. |
Vc(V) |
lp(A) |
|
JNR |
7~1000 |
9~1465 |
9.6~1620 |
12~1800 |
14,4~1980 |
25~2970 |
1~100 |
Application Scenario
Charger
LED lights
Kettle
Rice cooker
Induction cooker
Power supply
Sweeper
Washing machine
• Transistor, Diode, IC, Thyristor or Triac semiconductor protection.
• Surge protection in consumer electronics.
• Surge protection in industrial electronics.
• Surge protection in electronic home appliances, gas and petroleum appliances.
• Relay and electromagnetic valve surge absorption.
Production Process
1. Lead Forming
2. The Combination of Lead and Chip
3. Soldering
4. Soldering Inspection
5. Epoxy Resin Coating
6. Baking
7. Laser Printing
8. Electrical Performance Test
9. Appearance Inspection
10. Lead Cutting or Pulling Out
11. FQC and Packing
